Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 193.9 CFM (5.43m³/min) [1] |
| Bearing Type | Ball [1] |
| Base Product Number | EYW12038012 [1] |
| Current Rating (Amps) | 2.20A [1] |
| Fan Type | Tubeaxial [1] |
| Lifetime @ Temp. | 75000 Hrs @ 40°C [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Material - Frame | Polybutylene Terephthalate (PBT) [1] |
| Mfr | YS TECH USA [1] |
| Noise | 60.4dB(A) [1] |
| Power (Watts) | 26.4 W [1] |
| Product Status | Active [1] |
| RPM | 5000 RPM [1] |
| Series | EYW12038 [1] |
| Size / Dimension | Square - 120mm L x 120mm H [1] |
| Static Pressure | 1.150 in H2O (286.5 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 12VDC [1] |
| Voltage Range | 7 ~ 13.2VDC [1] |
| Width | 38.00mm [1] |
Specification references[1]YS TECH USA EYW12038012BM-12 vendor product record ↗
