Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| AC Voltage - Input | 90 ~ 264 VAC [1] |
| Applications | ITE (Commercial) [1] |
| Approval Agency | CE [1] |
| Current - Output (Max) | 5A [1] |
| Base Product Number | DSP100 [1] |
| Efficiency | 85% [1] |
| DC Voltage - Input (Max) | 370V [1] |
| Features | Adjustable Output, Universal Input [1] |
| DC Voltage - Input (Min) | 120V [1] |
| Input Type | AC or DC [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -25°C ~ 71°C (With Derating) [1] |
| Power (Watts) | 100W [1] |
| Manufacturer | TDK-Lambda [1] |
| Series | DSP (7.5-100W) [1] |
| Size / Dimension | 2.19" L x 3.54" W x 3.58" H (55.6mm x 89.9mm x 90.9mm) [1] |
| Part Status | Not For New Designs [1] |
| Voltage - Isolation | 3 kV [1] |
| Voltage - Output 1 | 15V [1] |
Specification references[1]TDK-Lambda DSP100-15 vendor product record ↗
