Peer-catalog SOD-323 package reference for Diodes Incorporated 1N4148WS-7-F

Representative package visualProduct reference1 of 2

Exact MPN17 sourced attributes1 manufacturer document

Diodes Incorporated · exact orderable part

1N4148WS-7-F

Diodes Incorporated switching diode with 75 V reverse voltage, 150 mA average rectified current and SOD323 package.

Reverse Voltage: 75 V
Forward Current: 0.15 A
Reverse Recovery Time: 4 ns
Package / Case: SOD323
Non-Repetitive Peak Reverse Voltage: 100 V
RMS Reverse Voltage: 53 V

Original manufacturerCommercial terms confirmed per lot

ManufacturerDiodes Incorporated

Package / caseSOD323

Mounting typesurface mount

Packing3000/reel

Technical parameters

Technical specifications

17 normalized values · 1 manufacturer source

Report a data issue

1N4148WS-7-F technical parameters
Parameter	Value
Reverse Voltage	75 V [1]
Forward Current	0.15 A [1]
Reverse Recovery Time	4 ns [1]
Package / Case	SOD323 [1]
Non-Repetitive Peak Reverse Voltage	100 V [1]
RMS Reverse Voltage	53 V [1]
Forward Continuous Current	0.3 A [1]
1 µs Surge Current	4 A [1]
1 s Surge Current	1 A [1]
Power Dissipation	200 mW [1]
Junction-to-Ambient Thermal Resistance	625 °C/W [1]
Junction Temperature Range	-55 to 150 °C [1]
Maximum Forward Voltage at 1 mA	0.715 V [1]
Total Capacitance	2 pF [1]
Approximate Package Weight	0.006 g [1]
Moisture Sensitivity Level	MSL 1 per J-STD-020 [1]
Terminal Count	2 [1]

Specification references[1]Diodes Incorporated 1N4148WS Datasheet, DS30097 Rev. 29-2, Feb 2025 ↗

Product overview

1N4148WS-7-F at a glance

Diodes Incorporated 1N4148WS-7-F is an exact orderable switching diodes device in SOD323. The reviewed technical record lists reverse voltage of 75 V and forward current of 0.15 A.

Key features

Verified device capabilities

Reverse Voltage: 75 V under the cited manufacturer conditions.
Forward Current: 0.15 A under the cited manufacturer conditions.
Reverse Recovery Time: 4 ns under the cited manufacturer conditions.
Package / Case: SOD323 under the cited manufacturer conditions.
Non-Repetitive Peak Reverse Voltage: 100 V under the cited manufacturer conditions.

Applications

Where the device is used

Electronic designs whose requirements match the documented reverse voltage, forward current, reverse recovery time.

Ordering information

Exact code and packing

1N4148WS-7-F identifies the exact Diodes Incorporated order code in SOD323 with 3000/reel packing recorded; current lot terms are confirmed in the quotation.

Design notes

Use the rating in context

Use the cited operating conditions for 1N4148WS-7-F; do not convert an absolute maximum, headline rating or family-level value into an unconditional board-level guarantee.

Quotation and fulfillment

What is confirmed before an order

Commercial facts belong to the quoted lot. The catalog does not invent live stock, price, date code or lead time.

Exact-part check

Manufacturer, full suffix, package, quantity and requested documentation are captured in the RFQ.

Lot-level quotation

Price, available quantity, date code, condition and lead time are written into the quotation when confirmed.

Inspection request

Label, marking, packing and traceability requirements can be specified before shipment.

Shipping and payment

Shipping method, Incoterm and available payment route are agreed in the commercial offer.

Technical and ordering FAQ

Questions buyers ask about 1N4148WS-7-F

Answers distinguish the IC itself from assembled modules and keep absolute limits separate from normal operating conditions.

What package does 1N4148WS-7-F use?

1N4148WS-7-F is recorded in SOD323. Confirm the complete suffix and packing in the quotation.

What is the documented reverse voltage?

The cited manufacturer record lists 75 V. Apply the source's test and operating conditions.

How should the forward current be interpreted?

The normalized catalog value is 0.15 A. The linked evidence controls its exact conditions and revision.

Does this page prove current 1N4148WS-7-F stock?

No. Technical evidence identifies the device; stock, date code, price, MOQ and lead time require a current verified offer or quotation.

Can 1N4148WS-7-F be replaced by a similar part without review?

No automatic drop-in claim is made. Compare electrical limits, package, pinout, functions and qualification before substitution.

Catalog relationships

Keep family and exact MPN intent separate.

This page describes one orderable part. A family page helps select suffixes but never carries assumed stock or a price.

ManufacturerDiodes IncorporatedView brand page →CategorySwitching DiodesView category page →Part family1N4148WSCompare exact variants →
