Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Type | Open Frame [1] |
| Base Product Number | DG200 [1] |
| Applications | Medical [1] |
| Voltage - Input | 90 ~ 264 VAC [1] |
| Approval Agency | CB, CE [1] |
| Voltage - Output 1 | 12V [1] |
| Current - Output 1 | 16.5 A [1] |
| Mounting Type | Chassis Mount [1] |
| Efficiency | 90% [1] |
| Features | PFC, Standby Output, Universal Input [1] |
| Mfr | Tri-Mag, LLC [1] |
| Minimum Load Required | No [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -20°C~65°C(WithDerating) [1] |
| Product Status | Active [1] |
| Power (Watts) | 200W (300W Forced Air) [1] |
| Size / Dimension | 5.00" L x 3.00" W x 1.42" H (127.0mm x 76.2mm x 36.1mm) [1] |
| Series | Tri-Mag, DG200 (200W) [1] |
| Voltage - Isolation | 4 kV [1] |
Specification references[1]Tri-Mag, LLC DG200M-7EU vendor product record ↗
