Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Contact Finish - Mating | Gold [1] |
| Base Product Number | D01-997 [1] |
| Contact Finish - Post | Tin [1] |
| Contact Finish Thickness - Mating | Flash [1] |
| Contact Material - Mating | Beryllium Copper [1] |
| Contact Material - Post | Brass [1] |
| Contact Finish Thickness - Post | 196.9µin (5.00µm) [1] |
| Contact Resistance | 10mOhm [1] |
| Current Rating (Amps) | 1 A [1] |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Harwin Inc. [1] |
| Mounting Type | Through Hole [1] |
| Number of Positions or Pins (Grid) | 3 (1 x 3) [1] |
| Operating Temperature | -55°C ~ 125°C [1] |
| Pitch - Mating | 0.100" (2.54mm) [1] |
| Pitch - Post | 0.100" (2.54mm) [1] |
| Product Status | Active [1] |
| Series | D01-997 [1] |
| Termination | Solder [1] |
| Termination Post Length | 0.125" (3.18mm) [1] |
| Type | SIP [1] |
Specification references[1]Harwin Inc. D01-9970342 vendor product record ↗
