Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Cable End Type | Straight, Tapered [1] |
| Connector/Contact Type | Contacts, Vertical - 1 Sided [1] |
| Contact Finish | Tin [1] |
| Contact Material | Phosphor Bronze [1] |
| Current Rating (Amps) | 0.5A [1] |
| FFC, FCB Thickness | 0.30mm [1] |
| Flat Flex Type | FFC, FPC [1] |
| Features | Low Insertion Force (LIF) [1] |
| Height Above Board | 0.197" (5.00mm) [1] |
| Housing Color | Natural [1] |
| Housing Material | Polyamide (PA6T), Nylon 6T, Glass Filled, Halogen Free [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Cvilux USA [1] |
| Mounting Type | Through Hole [1] |
| Number of Positions | 8 [1] |
| Operating Temperature | -40°C ~ 105°C [1] |
| Pitch | 0.039" (1.00mm) [1] |
| Product Status | Active [1] |
| Series | CF16 [1] |
| Termination | Kinked Pin [1] |
| Voltage Rating | 100V [1] |
Specification references[1]Cvilux USA CF16081V0T0-NH vendor product record ↗
