Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Cable End Type | Straight, Tapered [1] |
| Connector/Contact Type | Contacts, Top and Bottom [1] |
| Contact Finish | Tin [1] |
| Contact Material | Phosphor Bronze [1] |
| Current Rating (Amps) | 1A [1] |
| FFC, FCB Thickness | 0.30mm [1] |
| Flat Flex Type | FFC, FPC [1] |
| Features | Low Insertion Force (LIF), Solder Retention [1] |
| Height Above Board | 0.102" (2.60mm) [1] |
| Housing Color | Black [1] |
| Housing Material | Polyamide (PA), Nylon, Glass Filled, Halogen Free [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Cvilux USA [1] |
| Mounting Type | Surface Mount, Right Angle [1] |
| Number of Positions | 8 [1] |
| Operating Temperature | -25°C ~ 85°C [1] |
| Pitch | 0.039" (1.00mm) [1] |
| Product Status | Active [1] |
| Series | CF08 [1] |
| Termination | Solder [1] |
| Voltage Rating | 100V [1] |
Specification references[1]Cvilux USA CF08081H1R0-NH vendor product record ↗
