Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Control Features | Enable, Active Low [1] |
| Base Product Number | CC1R5 [1] |
| Current - Output (Max) | 300mA [1] |
| Mfr | TDK-Lambda [1] |
| Mounting Type | Through Hole [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -40°C ~ 85°C [1] |
| Power (Watts) | 1 W [1] |
| Part Status | Active [1] |
| Series | CC-E (1.5W) [1] |
| Size / Dimension | 0.65" L x 0.65" W x 0.34" H (16.5mm x 16.6mm x 8.5mm) [1] |
| Type | Isolated Module [1] |
| Voltage - Input (Max) | 9V [1] |
| Voltage - Input (Min) | 4.5V [1] |
| Voltage - Isolation | 500 V [1] |
| Voltage - Output 1 | 5V [1] |
Specification references[1]TDK-Lambda CC1R5-0505SF-E vendor product record ↗
