Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | Industrial [1] |
| Backshell Material, Plating | Polyamide (PA66), Nylon 6/6, Glass Filled [1] |
| Connector Type | Plug, Female Sockets [1] |
| Cable Opening | 0.236" ~ 0.472" (6.00mm ~ 12.00mm) [1] |
| Contact Finish - Mating | Silver [1] |
| Color | Black [1] |
| Fastening Type | Threaded [1] |
| Current Rating (Amps) | 10A, 16A [1] |
| Ingress Protection | IP67 - Dust Tight, Waterproof [1] |
| Insert Material | Polyamide (PA66), Nylon 6/6, Glass Filled [1] |
| Features | Backshell, Coupling Nut, Strain Relief [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Hirschmann [1] |
| Mounting Type | Free Hanging (In-Line) [1] |
| Number of Positions | 4 (3 + PE) [1] |
| Operating Temperature | -40°C ~ 90°C [1] |
| Orientation | Keyed [1] |
| Primary Material | Plastic [1] |
| Series | CA [1] |
| Product Status | Active [1] |
| Shell Material | Polyamide (PA66), Nylon 6/6, Glass Filled [1] |
| Shielding | Unshielded [1] |
| Termination | Screw [1] |
| Voltage Rating | 400VAC, 250VDC [1] |
Specification references[1]Hirschmann CA 3 LD vendor product record ↗
