ACM1602K-FLY-YBW representative package visual — not an exact-product photograph

Representative package visual — not an exact-product photographProduct referenceVendor-delivered DigiKey product/package image

Exact MPN15 sourced attributes1 source document

AZ Displays · exact orderable part

ACM1602K-FLY-YBW

16x2 CHARACTER LCD

Backlight: LED - Yellow/Green
Character Format: 5 x 8 Dots
Controller Type: AiP31066LC, ST7066U-0A
Character Size: 5.23mm H x 3.00mm W
Display Format: 16 x 2
Dot Size: 0.56mm W x 0.61mm H

Original manufacturerCommercial terms confirmed per lot

ManufacturerAZ Displays

Mounting typeunknown

PackingBox

Technical parameters

Technical specifications

15 normalized values · 1 validated source

Report a data issue

ACM1602K-FLY-YBW technical parameters
Parameter	Value
Backlight	LED - Yellow/Green [1]
Character Format	5 x 8 Dots [1]
Controller Type	AiP31066LC, ST7066U-0A [1]
Character Size	5.23mm H x 3.00mm W [1]
Display Format	16 x 2 [1]
Dot Size	0.56mm W x 0.61mm H [1]
Display Mode	Transflective [1]
Display Type	STN - Super-Twisted Nematic [1]
Mfr	AZ Displays [1]
Number of Characters	32 [1]
Operating Temperature	-20°C~70°C [1]
Outline L x W x H	80.00mm x 36.00mm x 13.50mm [1]
Product Status	Active [1]
Viewing Area	64.50mm L x 16.40mm W [1]
Voltage - Supply	4.8V ~ 5.2V [1]

Specification references[1]AZ Displays ACM1602K-FLY-YBW vendor product record ↗

Catalog relationships

Keep family and exact MPN intent separate.

This page describes one orderable part. A family page helps select suffixes but never carries assumed stock or a price.

ManufacturerAZ DisplaysView brand page →CategoryDisplay Modules - LCD, OLED Character and NumericView category page →
