Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Backlight | LED - Green [1] |
| Character Format | 5 x 8 Dots [1] |
| Controller Type | KS0066 [1] |
| Character Size | 5.23mm H x 3.00mm W [1] |
| Display Format | 16 x 2 [1] |
| Dot Size | 0.56mm W x 0.61mm H [1] |
| Display Mode | Transflective [1] |
| Display Type | STN - Super-Twisted Nematic [1] |
| Mfr | AZ Displays [1] |
| Number of Characters | 32 [1] |
| Operating Temperature | -20°C~70°C [1] |
| Outline L x W x H | 84.00mm x 44.00mm x 13.50mm [1] |
| Product Status | Active [1] |
| Series | ACM1602B [1] |
| Viewing Area | 64.50mm L x 16.00mm W [1] |
| Voltage - Supply | 4.75V ~ 5.25V [1] |
Specification references[1]AZ Displays ACM1602B-FL-GBS-GN vendor product record ↗
