Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Backlight | LED [1] |
| Character Format | 5 x 8 Dots [1] |
| Controller Type | ST7066U [1] |
| Character Size | 6.56mm H x 3.07mm W [1] |
| Display Format | 16 x 1 [1] |
| Dot Size | 0.55mm W x 0.57mm H [1] |
| Display Mode | Reflective [1] |
| Display Type | FSTN - Film Super-Twisted Nematic, STN - Super-Twisted Nematic, TN - Twisted Nematic [1] |
| Mfr | AZ Displays [1] |
| Operating Temperature | -20°C~70°C [1] |
| Outline L x W x H | 80.00mm x 36.00mm x 13.50mm [1] |
| Product Status | Active [1] |
| Series | ACM1601C [1] |
| Viewing Area | 64.50mm L x 14.00mm W [1] |
| Voltage - Supply | 2.7V ~ 5.5V [1] |
Specification references[1]AZ Displays ACM1601C-RN-YBH vendor product record ↗
