Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 239.0 CFM (6.69m³/min) [1] |
| Approval Agency | CE, CUR, TUV, UL [1] |
| Bearing Type | Ball [1] |
| Current Rating (Amps) | 0.110A [1] |
| Fan Type | Tubeaxial [1] |
| Material - Frame | Aluminum [1] |
| Mfr | Sunon Fans [1] |
| Noise | 58.0dB(A) [1] |
| Power (Watts) | 26.00W [1] |
| Material - Blade | Polybutylene Terephthalate (PBT) [1] |
| Product Status | Obsolete [1] |
| RPM | 3200 RPM [1] |
| Series | A [1] |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) [1] |
| Size / Dimension | Rectangular/Rounded - 171.5mm L x 151.5mm H [1] |
| Static Pressure | 0.690 in H2O (171.8 Pa) [1] |
| Termination | 2 Wire Leads [1] |
| Voltage - Rated | 240VAC [1] |
| Weight | 2 lbs (907.2 g) [1] |
| Width | 51.00mm [1] |
| Voltage Range | 150 ~ 250VAC [1] |
Specification references[1]Sunon Fans A2175HBL-TC vendor product record ↗
