Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 86406CY [1] |
| Cable Type | Multi-Pair [1] |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) [1] |
| Conductor Material | Copper, Tinned [1] |
| Conductor Strand | 7/36 [1] |
| Features | Biological Compatibility, Drain Wire [1] |
| Jacket (Insulation) Diameter | 0.293" (7.44mm) [1] |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) [1] |
| Jacket (Insulation) Thickness | 0.0450" (1.143mm) [1] |
| Jacket Color | Slate [1] |
| Mfr | Alpha Wire [1] |
| Length | 100.0' (30.5m) [1] |
| Number of Conductors | 12 (6 Pair Twisted) [1] |
| Product Status | Active [1] |
| Ratings | ISO 10993, UL Style 2661 [1] |
| Series | Xtra-Guard® Flex [1] |
| Shield Coverage | 100%, 85% [1] |
| Shield Material | Aluminum; Copper, Tinned [1] |
| Shield Type | Foil, Braid [1] |
| Voltage | 300 V [1] |
| Wire Gauge | 28 AWG [1] |
Specification references[1]Alpha Wire 86406CY SL005 vendor product record ↗
