Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 74HC14 [1] |
| Current - Output High, Low | 5.2mA, 5.2mA [1] |
| Current - Quiescent (Max) | 2 µA [1] |
| Features | Schmitt Trigger [1] |
| Input Logic Level - High | 1.5V ~ 4.2V [1] |
| Input Logic Level - Low | 1V ~ 3V [1] |
| Logic Type | Inverter [1] |
| Max Propagation Delay @ V, Max CL | 13ns @ 6V, 50pF [1] |
| Mfr | Renesas Electronics Corporation [1] |
| Number of Circuits | 6 [1] |
| Number of Inputs | 1 [1] |
| Operating Temperature | -55°C ~ 125°C [1] |
| Product Status | Active [1] |
| Series | 74HC [1] |
| Voltage - Supply | 2V ~ 6V [1] |
Specification references[1]Renesas Electronics Corporation 74HC14FPDEL-E vendor product record ↗
