Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Applications | ITE (Commercial) [1] |
| Approval Agency | CE, UKCA [1] |
| Current - Output (Max) | 10A [1] |
| Efficiency | 84% [1] |
| Mfr | Premium PSU [1] |
| Mounting Type | Chassis Mount [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -25°C ~ 80°C [1] |
| Power (Watts) | 120W [1] |
| Product Status | Active [1] |
| Series | CRS-120 [1] |
| Size / Dimension | 6.30" L x 3.94" W x 1.38" H (160.0mm x 100.0mm x 35.0mm) [1] |
| Type | Enclosed [1] |
| Voltage - Input (Max) | 72V [1] |
| Voltage - Input (Min) | 36V [1] |
| Standard Number | 60950-1; 62368-1 [1] |
| Voltage - Isolation | 4.2 kV [1] |
| Voltage - Output 1 | 12V [1] |
Specification references[1]Premium PSU 6770D vendor product record ↗
