Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 669333 [1] |
| Cable Type | Multi-Pair, Cat5e [1] |
| Conductor Insulation | Polypropylene (PP) [1] |
| Conductor Material | Copper, Bare [1] |
| Conductor Strand | 7/32 [1] |
| Features | Biological Compatibility [1] |
| Jacket (Insulation) Diameter | 0.310" (7.87mm) [1] |
| Jacket (Insulation) Material | Thermoplastic Elastomer (TPE) [1] |
| Jacket (Insulation) Thickness | 0.0330" (0.838mm) [1] |
| Jacket Color | Black [1] |
| Mfr | Alpha Wire [1] |
| Length | 1000.0' (304.8m) [1] |
| Number of Conductors | 4 (2 Pair Twisted) [1] |
| Operating Temperature | -50°C ~ 105°C [1] |
| Product Status | Active [1] |
| Ratings | ISO 10993 [1] |
| Series | Xtra-Guard® Cat5e Industrial Ethernet [1] |
| Shield Coverage | 100%, 90% [1] |
| Shield Material | Aluminum; Copper, Tinned [1] |
| Shield Type | Foil, Braid [1] |
| Voltage | 300 V [1] |
| Wire Gauge | 24 AWG [1] |
Specification references[1]Alpha Wire 669333 BK001 vendor product record ↗
