Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 6374 [1] |
| Cable Type | Multi-Pair [1] |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) [1] |
| Conductor Material | Copper, Tinned [1] |
| Conductor Strand | 7/28 [1] |
| Features | Drain Wire [1] |
| Jacket (Insulation) Diameter | 0.267" (6.78mm) [1] |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) [1] |
| Jacket (Insulation) Thickness | 0.0320" (0.813mm) [1] |
| Jacket Color | Slate [1] |
| Mfr | Alpha Wire [1] |
| Length | 100.0' (30.5m) [1] |
| Number of Conductors | 6 (3 Pair Twisted) [1] |
| Operating Temperature | -20°C ~ 80°C [1] |
| Product Status | Active [1] |
| Ratings | UL Style 2464 [1] |
| Shield Coverage | 100%, 65% [1] |
| Shield Material | Aluminum; Copper, Tinned [1] |
| Shield Type | Foil, Braid [1] |
| Voltage | 300 V [1] |
| Wire Gauge | 22 AWG [1] |
Specification references[1]Alpha Wire 6374 SL005 vendor product record ↗
