Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 5606B1601 [1] |
| Cable Type | Multi-Conductor [1] |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) [1] |
| Conductor Material | Copper, Bare [1] |
| Conductor Strand | 7/0.0192" [1] |
| Jacket (Insulation) Diameter | 0.300" (7.62mm) [1] |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) [1] |
| Jacket (Insulation) Thickness | 0.0500" (1.270mm) [1] |
| Jacket Color | Black [1] |
| Mfr | Alpha Wire [1] |
| Length | 100.0' (30.5m) [1] |
| Number of Conductors | 2 (1 Pair Twisted) [1] |
| Operating Temperature | -25°C ~ 90°C [1] |
| Product Status | Active [1] |
| Voltage | 600 V [1] |
| Wire Gauge | 16 AWG [1] |
Specification references[1]Alpha Wire 5606B1601 BK005 vendor product record ↗
