Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 5129/27C [2] |
| Cable Type | Multi-Pair [2] |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) [2] |
| Conductor Material | Copper, Tinned [2] |
| Conductor Strand | 7/30 [2] |
| Features | Biological Compatibility, Drain Wire, Rip Cord [2] |
| Jacket (Insulation) Diameter | 0.649" (16.49mm) [2] |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) [2] |
| Jacket (Insulation) Thickness | 0.0530" (1.346mm) [2] |
| Jacket Color | Slate [2] |
| Mfr | Alpha Wire [2] |
| Number of Conductors | 54 (27 Pair Twisted) [2] |
| Operating Temperature | -35°C ~ 105°C [2] |
| Product Status | Active [2] |
| Ratings | ISO 10993 [2] |
| Series | Xtra-Guard® 1 [2] |
| Shield Coverage | 100%, 70% [2] |
| Shield Material | Suprashield®; Copper, Tinned [2] |
| Shield Type | Foil, Braid [2] |
| Usage | Communication, Control [2] |
| Voltage | 300 V [2] |
| Wire Gauge | 22 AWG [2] |
