Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 45363 [1] |
| Cable Type | Multi-Conductor [1] |
| Conductor Insulation | Thermoplastic Elastomer (TPE) [1] |
| Conductor Material | Copper, Tinned [1] |
| Conductor Strand | 19/0.0117" [1] |
| Features | Biological Compatibility, Drain Wire, Rip Cord [1] |
| Jacket (Insulation) Diameter | 0.294" (7.47mm) [1] |
| Jacket (Insulation) Material | Thermoplastic Elastomer (TPE) [1] |
| Jacket (Insulation) Thickness | 0.0450" (1.143mm) [1] |
| Jacket Color | Black [1] |
| Mfr | Alpha Wire [1] |
| Length | Enter Number of Feet in Order Quantity [1] |
| Number of Conductors | 3 [1] |
| Operating Temperature | -50°C ~ 125°C [1] |
| Product Status | Active [1] |
| Ratings | ISO 10993 [1] |
| Series | Xtra-Guard® 4 [1] |
| Shield Coverage | 100% [1] |
| Spool Size | 1000.0' (304.8m) [1] |
| Shield Material | Aluminum [1] |
| Shield Type | Foil [1] |
| Voltage | 300 V [1] |
| Wire Gauge | 16 AWG [1] |
Specification references[1]Alpha Wire 45363 BK199 vendor product record ↗
