Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Type | Enclosed [1] |
| Applications | ITE (Commercial) [1] |
| Voltage - Input | 210 ~ 250 VAC [1] |
| Approval Agency | CE, cURus [1] |
| Voltage - Output 1 | 2V [1] |
| Current - Output (Max) | 400mA [1] |
| Mounting Type | Through Hole [1] |
| Features | Adjustable Output [1] |
| Line Regulation | ±0.05% [1] |
| Load Regulation | ±0.2% [1] |
| Manufacturer | Acopian Power Supplies [1] |
| Number of Outputs | 1 [1] |
| Operating Temperature | -20°C ~ 71°C [1] |
| Part Status | Active [1] |
| Size / Dimension | 3.53" L x 2.53" W x 1.04" H (89.7mm x 64.3mm x 26.4mm) [1] |
Specification references[1]Acopian Power Supplies 2E40A-230 vendor product record ↗
