Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Connector Type | Header [1] |
| Mfr | NorComp Inc. [1] |
| Contact Finish - Mating | Gold [1] |
| Product Status | Active [1] |
| Contact Finish - Post | Gold [1] |
| Series | 2664 [1] |
| Contact Finish Thickness - Mating | Flash [1] |
| Contact Finish Thickness - Post | Flash [1] |
| Contact Length - Post | 0.118" (3.00mm) [1] |
| Contact Material | Copper Alloy [1] |
| Contact Length - Mating | 0.150" (3.81mm) [1] |
| Contact Shape | Square [1] |
| Contact Type | Male Pin [1] |
| Current Rating (Amps) | 1A [1] |
| Fastening Type | Push-Pull [1] |
| Insulation Color | Black [1] |
| Insulation Height | 0.059" (1.50mm) [1] |
| Insulation Material | Polyamide (PA6T), Nylon 6T [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mounting Type | Through Hole [1] |
| Number of Positions | 6 [1] |
| Number of Positions Loaded | All [1] |
| Number of Rows | 2 [1] |
| Overall Contact Length | 0.327" (8.30mm) [1] |
| Operating Temperature | -40°C~105°C [1] |
| Pitch - Mating | 0.079" (2.00mm) [1] |
| Row Spacing - Mating | 0.079" (2.00mm) [1] |
| Shrouding | Unshrouded [1] |
| Style | Board to Board or Cable [1] |
| Termination | Solder [1] |
Specification references[1]NorComp Inc. 26640601RP2 vendor product record ↗
