Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 2423C [1] |
| Cable Type | Multi-Conductor [1] |
| Conductor Insulation | Polyethylene (PE) [1] |
| Conductor Material | Copper, Tinned [1] |
| Conductor Strand | 16/30 [1] |
| Features | Drain Wire [1] |
| Jacket (Insulation) Diameter | 0.214" (5.44mm) [1] |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) [1] |
| Jacket (Insulation) Thickness | 0.0200" (0.508mm) [1] |
| Jacket Color | Slate [1] |
| Mfr | Alpha Wire [1] |
| Length | Enter Number of Feet in Order Quantity [1] |
| Number of Conductors | 3 [1] |
| Operating Temperature | -20°C ~ 75°C [1] |
| Product Status | Active [1] |
| Ratings | UL Style 2093 [1] |
| Shield Coverage | 100% [1] |
| Spool Size | 2500.0' (762.0m) [1] |
| Shield Material | Aluminum [1] |
| Shield Type | Foil [1] |
| Usage | Communication, Control [1] |
| Voltage | 300 V [1] |
| Wire Gauge | 18 AWG [1] |
Specification references[1]Alpha Wire 2423C SL010 vendor product record ↗
