Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Connector Type | Header [1] |
| Mfr | Marutsuelec [1] |
| Contact Length - Post | 0.118" (3.00mm) [1] |
| Contact Length - Mating | 0.240" (6.10mm) [1] |
| Contact Shape | Square [1] |
| Contact Type | Male Pin [1] |
| Current Rating (Amps) | 3A [1] |
| Fastening Type | Push-Pull [1] |
| Insulation Color | Black [1] |
| Insulation Height | 0.100" (2.54mm) [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Part Status | Active [1] |
| Mounting Type | Through Hole [1] |
| Number of Positions | 2 [1] |
| Number of Positions Loaded | All [1] |
| Number of Rows | 1 [1] |
| Overall Contact Length | 0.457" (11.60mm) [1] |
| Operating Temperature | -40°C ~ 85°C [1] |
| Pitch - Mating | 0.100" (2.54mm) [1] |
| Shrouding | Unshrouded [1] |
| Style | Board to Board or Cable [1] |
| Termination | Solder [1] |
Specification references[1]Marutsuelec 2130S1*2GSE vendor product record ↗
