Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 1N4148 [1] |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz [1] |
| Current - Average Rectified (Io) | 125mA [1] |
| Current - Reverse Leakage @ Vr | 1 µA @ 75 V [1] |
| Mfr | Diodes Incorporated [1] |
| Grade | Automotive [1] |
| Mounting Type | Surface Mount [1] |
| Operating Temperature - Junction | -65°C ~ 150°C [1] |
| Product Status | Active [1] |
| Reverse Recovery Time (trr) | 4 ns [1] |
| Speed | Small Signal =< 200mA (Io), Any Speed [1] |
| Qualification | AEC-Q101 [1] |
| Technology | Standard [1] |
| Voltage - DC Reverse (Vr) (Max) | 80 V [1] |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA [1] |
Specification references[1]Diodes Incorporated 1N4148WTQ-7 vendor product record ↗
