Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Air Flow | 838.0 CFM (23.46m³/min) [1] |
| Approval Agency | CE, cUL, TUV, UL [1] |
| Bearing Type | Ball [1] |
| Current Rating (Amps) | 1.40A [1] |
| Fan Type | Tubeaxial [1] |
| Material - Frame | Magnesium Alloy [1] |
| Features | Auto Restart, Electronic Commutation, Locked Rotor Protection [1] |
| Mfr | Comair Rotron [1] |
| Lifetime @ Temp. | Varies Based on Temperature [1] |
| Noise | 74.0dB(A) [1] |
| Power (Watts) | 109W [1] |
| Material - Blade | Magnesium Alloy [1] |
| Product Status | Active [1] |
| RPM | 4000 RPM [1] |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) [1] |
| Size / Dimension | Square - 225mm L x 225mm H [1] |
| Static Pressure | 1.580 in H2O (393.7 Pa) [1] |
| Termination | Terminal Block [1] |
| Voltage - Rated | 115VAC [1] |
| Weight | 4.1 lbs (1.9 kg) [1] |
| Width | 80.00mm [1] |
| Voltage Range | 103 ~ 126VAC [1] |
Specification references[1]Comair Rotron 17000659A vendor product record ↗
