Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 164A174 [1] |
| Color | Black [1] |
| Connector Style | D-Sub, High Density [1] |
| Connector Type | Receptacle, Female Sockets [1] |
| Contact Finish | Gold [1] |
| Contact Finish Thickness | Flash [1] |
| Contact Form | Machined [1] |
| Contact Material | Copper Alloy [1] |
| Contact Type | Signal [1] |
| Current Rating (Amps) | 3A [1] |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled [1] |
| Flange Feature | Mating Side (4-40) [1] |
| Features | Board Lock [1] |
| Ingress Protection | IP20 [1] |
| Material Flammability Rating | UL94 V-0 [1] |
| Mfr | Amphenol CONEC [1] |
| Mounting Type | Through Hole [1] |
| Number of Positions | 44 [1] |
| Number of Rows | 3 [1] |
| Operating Temperature | -55°C ~ 125°C [1] |
| Series | 164A [1] |
| Shell Material, Finish | Steel, Tin Plated [1] |
| Part Status | Active [1] |
| Shell Size, Connector Layout | 3 (DB, B) High Density [1] |
| Termination | Solder [1] |
| Voltage Rating | 60V [1] |
Specification references[1]Amphenol CONEC 164A17479X vendor product record ↗
