Technical parameters
Technical specifications
| Parameter | Value |
|---|---|
| Base Product Number | 163X101 [1] |
| Color | Black [1] |
| Connector Style | D-Sub, High Density [1] |
| Connector Type | Plug for Male Contacts [1] |
| Contact Type | Signal [1] |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled [1] |
| Flange Feature | Housing/Shell (Unthreaded) [1] |
| Features | Grounding Indents [1] |
| Ingress Protection | IP20 [1] |
| Manufacturer | Amphenol CONEC [1] |
| Mounting Type | Free Hanging (In-Line) [1] |
| Note | Contacts Not Included [1] |
| Number of Positions | 15 [1] |
| Number of Rows | 3 [1] |
| Operating Temperature | -55°C ~ 125°C [1] |
| Part Status | Active [1] |
| Shell Finish Thickness | 320µin (8.13µm) [1] |
| Series | 163X [1] |
| Shell Material, Finish | Steel, Tin Plated [1] |
| Shell Size, Connector Layout | 1 (DE, E) High Density [1] |
Specification references[1]Amphenol CONEC 163X10169X vendor product record ↗
