0306-00120 representative package visual — not an exact-product photograph
Representative package visual — not an exact-product photographProduct referenceVendor-delivered DigiKey product/package image
Exact MPN7 sourced attributes1 source document

Traktronix · exact orderable part

0306-00120

POLARIS GEM CAR BRAKE SWITCH

Actuator Type
Lever, Simulated Roller
Circuit
SPDT
Mfr
Traktronix
Mounting Type
Chassis Mount
Product Status
Active
Termination Style
Quick Connect
Original manufacturerCommercial terms confirmed per lot
ManufacturerTraktronix
Mounting typeunknown
PackingBulk

Technical parameters

Technical specifications

7 normalized values · 1 validated source

Report a data issue
ParameterValue
Actuator TypeLever, Simulated Roller [1]
CircuitSPDT [1]
MfrTraktronix [1]
Mounting TypeChassis Mount [1]
Product StatusActive [1]
Termination StyleQuick Connect [1]
Switch FunctionOn-On [1]
Specification references[1]Traktronix 0306-00120 vendor product record ↗
